9-button programming control keypad with knob, lock and PoE function

Model: BYOD-1000A
Supports 9 control buttons(8-button and 1-knob and one lock)
Supports Lock button to lock/unlock key operations
Supports 2*RS232, 2*RELAY, 1*LAN(POE):TCP, UDP, HTTP control protocols
Supports WEB GUI, APP, 3rd party controls
Supports WEB GUI and APP programming
Supports POE or DC power supplies
Support UK single-gang or US double-gang size

Catégories : Processeurs de contrôle, Système de contrôle, Produit

DEMANDE DE RENSEIGNEMENTS

Description
Examens (0)

Introduction

BYOD-1000A (Hereinafter referred to as the Keypad) is a 9-button keypad controller aimed at providing customers simple and economic control solutions. With built-in PoE, it can receive power from PoE enabled ethernet switch. The keypad can control devices like presentation switches through LAN(PoE),RS232 or relay ports to control other devices, it also can support the 3^rd party control via commands. It supports WEB GUI/APP control/programming, also system firmware update, configuration save/restore on web UI. Available in both UK single or US double-gang size panels.

Caractéristiques

Supports 9 control buttons(8-button and 1-knob and one lock)
Supports Lock button to lock/unlock key operations
Supports 2*RS232, 2*RELAY, 1*LAN(POE):TCP, UDP, HTTP control protocols
Supports WEB GUI, APP, 3rd party controls
Supports WEB GUI and APP programming
Supports POE or DC power supplies
Support UK single-gang or US double-gang size

Spécifications

Item	Spécifications
Control Ports	2RS232 , 2RELAY , 1*LAN(POE)
ESD Protection	Human Body Discharge Mode: ± 8kV (Air Discharge), ± 4kV
Power Supply	DC 12V 1.5A
Power Consumption	Maximum 3.6W
UK Dimensions (mm)	86 mm (W) × 86 mm (D) × 39.8 mm (H)
Poids	280g
Température de fonctionnement	0 ºC ~ 40 ºC / 32 ºF ~ 104 ºF
Température de stockage	−20 ºC ~ 60 ºC / −4 ºF ~ 140 ºF
