Введение
This TV Wall controller is designed to be a truly capture, AD convert, route, distribute all-format signal to the video wall(LCD displays), while maintaining a true digital signal.
The controller with many different video interfaces, include 2 HDMI inputs with 4K30 resolution and 4 HDMI outputs with 1080P resolution. Supports different Video Wall modes, 1×2, 1×3, 1×4, 2×2 etc, with the 4K input and 1080P output, it can realize the point to point display. Support the 3.5mm audio de-embedded and with volume knob for sound adjustment. This controller can be controlled by remote control and front buttons.
Характеристики
- Supports 2 HDMI inputs, resolution up to 4K30
- Supports image 180 degrees rotation(good for the ceiling installation)
- Supports 4 HDMI with 1080P60 resolution outputs
- Supports multiple splicing ways: 2×2, 1×4, 4×1, 1×3 …
- Supports the splicing edge adjustment
- Supports HDMI 1.4, HDCP compatible
- Supports the IR remote and push-button control
Технические характеристики
| Product name | 4K TV wall controller |
| Управление | Front buttons, remote control |
| Вход | 2* HDMI(up to 4K30 resolution) |
| Выход | 4*HDMI(up to 1080P60) |
| Разрешение | 4k30 input and 1080@60Hz output |
| Display splice mode | 2×2, 1×4, 4×1, etc… |
| Power Supply | DC 12V3A |
| Power Consumption | 10W |
| Dimension (WxHxD) | 240*167*27(mm)/ 9.45*6.58*1.07(inch) |
| Вес | 2.5KG/ 5.5lbs |
| Operating Temperature | -10℃ to 50℃ |
| Температура хранения | -25℃ to 55℃ |
Схема подключенияProduct size:
