Introdução
This is a 4K60 HDCP2.3 adjuster with EDID management and audio de-embedded functions. It supports power supply via the 5V output from an HDMI signal source, enables lossless transmission of 4K@60Hz RGB signals, and allows signal frequency adjustment through physical DIP switches. The device integrates HDCP 2.3/1.4 adjustment functionality to resolve compatibility issues with encrypted signals, and simultaneously provides a 3.5mm analog audio separation output.
It is suitable for scenarios requiring cross-generation device collaboration, such as radio and television production, medical imaging, and digital signage. It ensures seamless signal connection through hardware-level processing.
Recursos
- Supports HDMI 2.0, with a maximum resolution of 4096×2160@60Hz
- Supports audio de-embedding
- Supports EDID management
- Supports visual LED indicators to show power and working status
- Supports DC12v or HDMI 5V power supply
- Supports HDCP2.3/1.4 adjustment
Especificação
| Descrição | HDMI Decryption Device |
| Entrada | 1×HDMI |
| Saída | 1×HDMI, 1×Analog Audio |
| Protocol Standards | Supports HDMI 1.4, HDCP 1.4, HDMI 2.0, HDCP 2.2 |
| Espaço de cores | Supports RGB 444, YUV 444, YUV 422, and x.v.Color s |
| Resolução | 640×480 – 3840×2160@60Hz (VESA); 480i – 4K@60Hz (HDTV) |
| EDID Management | DIP Switches |
| Fonte de alimentação | DC12V 1.5A |
4-PIN DIP Switch setting table
| DIP 1 | DIP 2 | DIP 3 | Function | DIP 4 |
| 0 | 0 | 0 | Bypass | 0: Same resolution as input 1: Auto scaling |
| 0 | 0 | 1 | DVI-1080 | |
| 0 | 1 | 0 | DVI-1200 | |
| 1 | 0 | 0 | 1080P2.1 | |
| 0 | 1 | 1 | 1280×720 (1280*800A) | |
| 1 | 0 | 1 | HDMI-1200 | |
| 1 | 1 | 0 | 4k2.1 | |
| 1 | 1 | 1 | 4k60 |
Diagrama de conexão
Product size(mm)
